• 250mm/s high-speed printing
• Low power consumption and low operating cost
• Integrated motherboard with three interfaces, good stability
• Separate cutter and print head in mechanism
• Inverted motherboard, specially designed for the kitchen to prevent oily smoke
• Support Serial+USB+100M Ethernet interface
• Use 100M network card, connect and print faster, avoid losing orders
• Automatically resume printing after network disconnection
• Standard GB18030 simplified/traditional Chinese character library
• Built-in data buffer
• Characters can be enlarged, bold, underlined and printed, and the character spacing can be adjusted
• Support different density bitmaps and download graphics printing
• Support network printing status monitoring, multi-connection printing on computer
• Support printer authentication, software binding
• Compatible with ESC/POS printing command set, the number of characters and fonts printed in each line are optional (adjust DIP switch)
Print method | Direct thermal | |
Print density | 576 dots/line or 512 dots/line | |
Print speed | 250mm/s | |
Interface | Serial+USB+Ethernet | |
Print width | 79.5±0.5mm | |
Media thickness | 0.06~0.08mm | |
Media outer diameter | 83mm | |
Fonts | Simplified Chinese GB18030 font library | |
Print command | Compatible with ESC/POS commands | |
Character size | ANK character: Font A: 12*24 dots, Font B: 9 * 17 dots | |
Barcode type | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/ITF/CODABAR/CODE93/CODE128 | |
Power supply | Adapter output | DC 24/2A |
Printer input | DC 24/2A | |
Cash drawer | DC 24/1A | |
Adapter input | AC 110V/220V, 50-60HZ | |
Physical characteristics | Printer weight | 1.4KG |
Printer dimension | 200*146*138mm(W*D*H) | |
Environmental factors | Working environment | Temperature: 5 ~ 45℃, humidity: 10 ~ 80% |
Storage environment | Temperature: -10 ~ 50℃, humidity: 10 ~ 90% (no condensation) | |
Reliability | Print head (reliability) | 150KM |
* The above parameters are subject to change without notice. |
