Print method

Direct thermal

Resolution

203DPI

Print speed

2~6 inch/s

Print width

76 mm

Print head temperature detect

Thermal sensitive resistance

Print head position detect

Mircoswitch

Paper detect

Photoelectric sensor

Memory

DRAM:8M FLASH:4M

Interface

USB+Serial+Ethernet

Graphics

Monochrome PCX, BMP and other graphics files can be downloaded to FLASH/DRAM

Barcode

CODE128, EAN128, ITF, CODE39, CODE93, EAN13，EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR，POSTNET, UPC-A, UPC-A+2, UPC-A+5, UPC-E, UPC-E+2，UPC-E+5，CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14/QRCODE

Character set

Common single-byte fonts: FONT 0 to FONT 8

Character enlargement / Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

Media type

Thermal roll paper, self-adhesive paper, etc.

Media width   (with backing paper)

25-82mm

Media roll core size

25.4mm

Media roll inner diameter

25mm (min.)

Media roll outer diameter

97mm (max)

Paper output method

Front paper output / peel off / tear-off

Input

input: DC24V 2.5A

Working environment

5~40℃, 20~90%RH

Storage environment

-25~55℃, 20%~93%RH

Printer weight

1.62kg

Printer dimension

231×156×145mm

Packing dimension

260×210×230mm

Print head (reliability)

30km

Printer certificate

CE, FCC, CCC, RoHS, SRRC
