Print method

Direct thermal

Print command

Compatible with ESC/POS commands

Resolution

203DPI

Print speed

70mm/s

Print width

48mm（max）

Print head temperature detect

Thermal sensitive resistance

Print head position detect

Microswitch

Paper detect

Photoelectric sensor

Memory

FLASH:60K

Interface

Standard:USB
Standard:USB+Bluetooth

Graphics

Support different density bitmap printing

Bar code

UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/ITF/CODABAR/CODE39/CODE93
/CODE128/QRCode

Character set

ANK character:
Font A: 12×24 dots
Font B: 9×17 dots
Simplified/Traditional Chinese: 24×24 dots

Character enlargement/rotation

1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing

Media type

Thermal paper

Media width

57.5+0.5mm

Media thickness

0.06~0.08mm

Media diameter

60mm

Media output method

Top paper output

Power supply

Input: DC 9V 2A

Working environment

0~40℃, 30%~90% non-condensing

Storage Environment

-20~55℃, 20%~93% non-condensing

Printer weight

0.62kg

Printer dimension

149×123×101.5mm

Packing dimension

180×150×125mm

Print head (reliability)

50km

Printer certificate

CE, FCC, CCC, RoHS, SRRC

* The above parameters are subject to change without notice.
