• 2 inches print width
• 3-5 inch/sec printing speed
• Printer size: 200×116×141mm, weight 1.1 kg
• Support 2M DRAM memory
• Automatic label detection, supports simplified, traditional Chinese and Korean
• Suport BMP, PCX, BAS files download and storage
• Communication interface: USB + Serial port
Item | Properties | Label mode | Receipt mode |
Print method | Direct thermal | Line thermal | |
Resolution | 203DPI | 203DPI | |
Print width | 56mm(max) | 48mm(max) | |
Print speed | 127mm/s(max) | 90mm/s | |
Memory | FLASH:60K | FLASH:60K | |
Print head temperature detect | Thermal sensitive resistance | Thermal sensitive resistance | |
Print head position detect | Microswitch | Microswitch | |
Paper detect | Photoelectric sensor | Photoelectric sensor | |
Interface | USB (Standard) | USB (Standard) | |
Barcode | Bar code | CODE128、EAN128、ITF、CODE39、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、POSTNET、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、CPOST、MSI、MSIC、PLESSEY、ITF14、EAN14、QRCODE | UPCA/UPC-E/JAN13(EAN13)/ |
Character enlargement/rotation | 1 ~10 times enlargement in portrait and landscape orientation; 0°, 90°, 180°, 270°degree rotation | 1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing | |
Graphics | Monochrome PCX, BMP graphics files | Support different density bitmap printing | |
Character set | Simplified Chinese GB18030, Traditional Chinese BIG5, Korean, Japanese (optional) | Simplified Chinese GB18030, Traditional Chinese BIG5, Korean, Japanese (optional) | |
Media | Media type | Thermal paper roll /adhesive thermal paper | Thermal paper roll |
Media width | 25-60mm(including backing paper) | 57.5±0.5mm | |
Media roll outer diameter | 110mm | ||
Media roll core size | Min. 25.4mm | ||
Media output method | Top paper output, tear-off | ||
Power supply | Power input | DC12V 4A | |
Environmental requirements | Working environment | 5~40℃,20%~90% non-condensing | |
Storage environment | -25~55℃,20%~93% non-condensing | ||
Physical characteristics | Printer dimension | 200mm×116mm×141mm | |
Packing dimension | 295mm×215mm×185 mm | ||
Printer weight | 1.1kg | ||
Printer certificate | CCC、RoHS、SRRC | ||
* The above parameters are subject to change without notice. |
