Print method

Direct thermal

Resolution

203DPI

Print speed

2~5 inch/s

Print width

76mm (max)

Print head temperature detect

Thermal sensitive resistance

Print head position detect

Mircoswitch

Paper detect

Photoelectric sensor

Memory

DRAM:2M FLASH:2M

Interface

USB, USB+Bluetooth,USB+Wi-Fi (optional)

Graphics

Monochrome PCX, BMP and other graphics files can be downloaded to FLASH/DRAM

Barcode

CODE128/EAN128/ITF/CODE39/CODE93/EAN13/EAN13+2/
EAN13+5/EAN8/EAN8+2/EAN8+5/CODABAR/POSTNET/
UPCA+2/UPCA+5/UPCE+2/UPC-E+5/CPOST/MSI/MSIC/
PLESSEY/ITF14/EAN14/QRCODE

Character set

Common single-byte fonts: FONT 0 to FONT 8

Character enlargement / Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

Media type

Thermal roll paper, self-adhesive paper, etc.

Media width   (with backing paper)

25-82mm

Media roll core size

25.4mm

Media roll inner diameter

25mm (min)

Media roll outer diameter

115mm (max)

Paper output method

Top paper output

Input

input: DC24V 2.5A

Working environment

5~40℃, 20~90%RH

Storage environment

-25~55℃, 20%~93%RH

Printer weight

1.2kg

Printer dimension

219×152×143mm

Packing dimension

260×210×230mm

Printer certificate

CE, FCC, CCC, RoHS, SRRC
