• 2~8inch high speed printing
• Print one label per second, without ribbon and toner
• Customized large gears are designed for fast printing
• 120mm paper width to fit for logistics express label
• Larger paper roll OD to improve your printing efficiency
• Gainscha self-developed automatic paper detection function
• Dual-sensors to prevent printing pause and paper skipping
• Support barcode and QR code printing
• Meet the different requirements of the media width between 40-118mm, simple operation.
• Automatic paper detection function
• Automatic temperature control
Print mode | Direct thermal |
Print command | TSPL |
Resolution | 203DPI |
Print speed | 2~8inch/s |
Print width | 104mm(max) |
Label length | 10-2286mm(0.39"~90") |
Print head temperature detect | Thermal sensitive resistance |
Print head position detect | Mircoswitch |
Black mark position detect | Reflective sensors |
Paper detect | Transmissive sensor |
Memory | DRAM:8M FLASH:4M |
Interface | USB, USB+Bluetooth, USB+Wi-Fi (optional) |
Graphics | Monochrome PCX, BMP and other graphics files can be downloaded to FLASH/DRAM |
Barcode | CODE128, EAN128, ITF, CODE39, CODE93, EAN13,EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR,POSTNET, UPC-A, UPC-A+2, UPC-A+5, UPC-E, UPC-E+2,UPC-E+5,CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14, QRCODE |
Character set | Common single-byte fonts: FONT 0 to FONT 8 |
Character enlargement / Rotation | 1 ~10 times enlargement in portrait and landscape orientation; 0°, 90°, 180°, 270°degree rotation |
Media type | Continuous, die-cut, fan-fold, black mark |
Media width (with backing paper) | 40mm-118mm |
Media roll core size | 25.4mm~38mm(1"~1.5") |
Media thickness (with backing paper) | Max.0.254mm(10mil), min. 0.06mm(2.36mil) |
Media diameter | 130mm(OD) |
Paper output method | Front paper output |
Input | input: DC24V 2.5A |
Operation environment | 5~40℃, 20~90%RH |
Storage environment | -25~55℃, 20%~93%RH |
Printer weight | 2.09kg |
Printer dimension | 285mmx210mmx180mm |
Packing dimension | 310mm×230mm×205mm |
Print head (reliability) | 30km |
Printer certificate | CE, FCC, CCC, RoHS |
