Print mode

Direct thermal

Print command

TSPL

Resolution

203DPI

Print speed

2~8inch/s

Print width

80mm

Overheat protection

Thermistor

Head position detection

Microswitch

Media detection

Photosensor

Memory

DRAM:8M FLASH:8M

Interface

USB、USB+Bluetooth（optional）、USB+Serial+Ethernet（optional）

Graphics

Monochrome PCX, BMP and other graphics files printing can download to FLASH/DRAM

Barcode

CODE128/EAN128/ITF/CODE39/CODE93/EAN13/EAN13+2/
EAN13+5/EAN8/EAN8+2/EAN8+5/CODABAR/POSTNET/
UPCA+2/UPCA+5/UPCE+2/UPC-E+5/CPOST/MSI/MSIC/
PLESSEY/ITF14/EAN16/QRCODE

Character set

Common single-byte fonts：FONT 0 to FONT 8
TST24、TSS24

Character enlargement / Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation printing

Media type

Thermal paper roll（Continuous, die-cut）

Media width (with liner)

最大85mm（4.72"）最小30mm（0.78"）

Media roll size

25.4mm

Meida core diameter

100mm

Media output method

Front paper output/tear-off

Power supply

input:DC24V 2.5A

Operation environment

5～45℃，20%～90%non-condensing

Storage environment

-20～55℃，20%～93%non-condensing

Printer N.W

1.1kg

Printer dimension

188×146×136 mm

Packing dimension

215×295×185 mm

Box dimension

675*320*400

Packing G.W.

12.420kg

quantity/box

6

Print head (reliability)

30KM

Printer certificate

CCC、RoHS

* The above parameters are subject to change without notice.
