Printing

Print Mode

Direct thermal

Print Speed

2-8 inch/s

Interface

USB+USB HOST+Ethernet

Resolution

203dots/inch (8dots/mm)

Dot Size

0.125x0.125mm (1mm=8dots)

Print Width

Max 104mm (4.09")

Print Length

2286mm (90")

Print Head

Temperatur sensor: thermal sensitive ressistance

Pisition sensor: microswith

Memory

DRAM: 2M FLASH: 2M

Pulse excitation

1X10*

Printer language

EPL

Media

Paper Roll OD

130mm OD

Paper Type

Continuous paper , paper with interspaces , folding paper ,black mark paper etc.

 PaperRolling Up Method

Printing side outward rolling

  Paper Width

Max. 120mm (4.72")   Min. 20mm (0.78")

  Paper Thickness

Max. 0.254mm (10mil)   Min. 0.06mm (2.36mil)

  Paper Roll Core Size

25.4mm~38mm (1"~1.5")

  Paper Gap

Min. 2 mm (0.09")

  Label Length

10~2286mm (0.39"~90")

Remark: If label length is less than 25.4mm(1 inch), the label paper with perforated line are recommended in order to tear off the labels easily.

Physical properties

  Weight

2.09kg

  Dimension

285*210*180mm(W*D*H)

Environment

  Work Environment

Temperature: 5 ~ 45℃, Humidity: 25 ~ 85%

  Storage Environment

Temperature: -10 ~ 50℃, Humidity: 10 ~ 90%

Reliability

Print head

30KM

Power

  Power Supply

The built-in voltage automatic switching power supply

Input: AC 110V/240V, Output: 50 ~ 60Hz, DC 24V/2A
