Print consumables

thermal paper, gap paper, black mark paper, continuous paper

Applicable Scene

Supermarket, food takeaway, catering, medical, clothing, tea, baking chain stores, etc.

Print method

Label

Receipt

Print command

TSPL

ESC/POS Command

Print resolution

203DPI

203DPI

Print width

56mm（max）

48mm（max）

Print speed

127mm/s（max）

90mm/s

Memory

FLASH：60K

FLASH：60K

Print head temperature detect

Thermistor

Thermistor

Paper detect

photoelectric sensor

photoelectric sensor

Printer Interfaces

USB+Wi-Fi

USB+Wi-Fi

Graphics

Monochrome BMP and other image files can be downloaded to FLASH

Support different density bitmap printing, ASCII Fonts

1D Barcode / 2D Barcode

CODE128/EAN128/ITF/CODE39/CODE93/EAN13/EAN13+2/EAN13+5/EAN8/EAN8+2/EAN8+5/CODEBAR/UPC_AU/PCA+2/UPCA+5UPC_E/UPCE+2/UPC_E+5/QRCODE

UPC_A/UPC_E/JAN13(EAN13)/JAN8（EAN8）/CODE39/CODEBAR/ITF/CODE93/CODE128/QRCode

Character Fonts

Commonly used single-byte fonts, FONT0 to FONT8, GB18030 Fonts,
Simplified/Traditional Chinese, Korean

ANK Fonts
FontA: 12*24dot
FontB: 9*17dotSimplified/Traditional Chinese, Korean:24*24dot

Character Enlargement / Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing

Media type

Thermal Paper Roll / Adhesive thermal paper

Thermal Paper Roll

Media width

25-60mm（with back paper）

57.5±0.5mm

Media diameter

80mm（max）

80mm（max）

Media thickness

Max 0.25mm； Min 0.06mm

Media output method

Top paper output

Power input

DC8.5V 3A

Cash drawer output

DC 12V/1A

Working environment

5~45℃（41~113℉），25~85%RH

Storage environment

5~45℃（41~113℉），25~85%RH

Printer weight

0.50kg

Printer dimensions

174mm×138mm×128mm

Packing dimension

240mm×150mm×135mm

Print head (reliability)

30km

Printer certificate

CCC

* The above parameters are subject to change without notice.
