GP-1834TC/1834TP/1835TC

4" High configuration thermal transfer barcode printer



  • perfomance
  • paramenters


• Come with cutter and peeler, automatic paper cutting and peeling, high work efficiency
• High speed printing, convenient to use
• User-friendly damping design of closing cover to avoid accidental injury
• Easy loading or changing paper roll
• Optional multiple interfaces and configurations increase the flexibility of applications
• 120mm paper exit chute, 104mm printing width, 127mm paper OD,  external paper holder support for various large paper rolls
• Multi-function printing, thermal transfer/direct thermal modes can be switching freely, suitable for various industries, flexible selecting consumables
• All-in-one structure design, rugged and durable, multiple interfaces to meet all your printing requirements
• Dual sensor design, automatic paper detection, transmissive and reflective sensors,  accurate printing, paper-saving and energy-saving



Model

GP-1834TC
GP-1834TP

GP-1835TC

Applications

Supermarket, catering, clothing, logistics, tea, baking chain stores, etc.

Print mode

Direct thermal / Thermal transfer

Print command

TSPL

Resolution

300DPI

Print speed

2~5inch/s

Print width

106mm

Overheat protection sensor

Yes

Paper detect sensor

Yes

Black mark detect sensor

Yes

Head open detect sensor

Yes

Media end error sensor

Yes

Memory

DRAM:8MB FLASH:4MB

Interface

Serial+USB+Parallel (standard)

USB+Parallel+Serial+Ethernet (standard)

USB+Bluetooth, USB+Wi-Fi (optional)

Graphics

Monochrome PCX, BMP and other graphics files can be downloaded to FLASH/DRAM

1D Barcode
2D Barcode

CODE128EAN128ITFCODE39EAN13EAN13+2EAN13+5EAN8EAN8+2EAN8+5CODABARPOSTNETUPC-AUPC-A+2UPC-A+5UPC-EUPC-E+2UPC-E+5CPOSTMSIMSICPLESSEYITF14EAN14QRCODE

Character set

Common single-byte fonts: FONT 0 to FONT 8

Character enlargement /
Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

Media type

Continuous, die-cut, fan-fold, black mark

Media width (include backing paper)

Max.120mm (4.72"), Min.20mm (0.78")

Media roll OD

127mm5"OD

Media thickness

Max.0.254mm ((10mil).  Min.0.06mm (2.36mil)

Media roll core size

1inch25.4mm

Ribbon OD

Max.67mm

Ribbon length

300m

Ribbon core size

1inch25.4mm

Ribbon width

Max.110mmMin.30mm

Ribbon rolling up method

Outward rolling

Media handling

Tear off

Cut off, peel off (optional)

Media output method

Front paper output

Power supply

input: DC24V 2.5A

Operation condition

5~40, 20~90%RH

Storage condition

-25~55, 20%~93%RH

Printer weight

2.50kg

Printer dimension

278x210x180mm

Packing dimension

370×260×235mm

Print head (reliability)

30km

Printer certificate

CCC, CE, FCC, RoHS, SRRC

CCC, CE, FCC, RoHS
