Item

Properties

Label mode

Receipt mode

Print

Print method

Direct thermal

Line thermal

Resolution

203DPI

203DPI

Print width

56mm（max）

48mm（max）

Print speed

127mm/s（max）

90mm/s

Memory

FLASH：60K

FLASH：60K

Print head temperature detect

Thermal sensitive resistance

Thermal sensitive resistance

Print head position detect

Microswitch

Microswitch

Paper detect

Photoelectric sensor

Photoelectric sensor

Interface

USB (Standard)
USB+Bluetooth(Optional)

USB (Standard)
USB+Bluetooth(Optional)

Barcode
Character
Graphics

Bar code

CODE128/EAN128/ITF/CODE39
/CODE93/EAN13/EAN13+2/EAN13+5
/EAN8/EAN8+2/EAN8+5/CODEBAR
/UPC_AU/PCA+2/UPCA+5UPC_E
/UPCE+2/UPC_E+5/QRCODE

UPCA/UPC-E/JAN13(EAN13)/
JAN8(EAN8)/CODE39/CODABAR/
ITF/CODE93/CODE128/QRCODE

Character enlargement/rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing

Graphics

Monochrome PCX, BMP graphics files

Support different density bitmap printing

Character set

Simplified Chinese GB18030, Traditional Chinese BIG5, Korean, Japanese (optional)

Simplified Chinese GB18030, Traditional Chinese BIG5, Korean, Japanese (optional)

Media

Media type

Thermal paper roll /adhesive thermal paper

Thermal paper roll

Media width

25-60mm(including backing paper)

58mm

Media roll outer diameter

80mm（max）

Media roll core size

12.7mm

Media output method

Top paper output,tear off

Power supply

Power input

DC 8.5V/3A

Cash drawer output

DC 12V/1A

Environmental requirements

Working environment

5~40℃，20%~90% non-condensing

Storage environment

-25~55℃，20%~93% non-condensing

Physical characteristics

Printer dimension

174×138×128mm

Packing dimension

240×150×137mm

Printer weight

0.67kg

Printer certificate

CCC、RoHS、SRRC
