Print method

Direct thermal

Print Instructions

TSPL

ESC/POS

Resolution

203DPI

Print speed

default:100mm/s，Max: 127mm/s

Factory default:120mm/s

Print width

56mm

48mm

Print head temperature detection

Thermistor

Print head position detection

Microswitch

Paper detection sensor

Thru Beam Sensors (left)

Memory

SRAM:1M  FLASH:8M

Button

Pause button, Feed button

Interface

Standard：USB
optional：USB+bluetooth

USB specifications

USB 2.0 Type-B

USB VID PID

VID:6868 PID:0500

Max. printing specifications

55mm×300mm

\

Graphics

Monochrome PCX, BMP and other graphics files printing

Support different density bitmap printing

Barcode

CODE128、EAN128、ITF、CODE39、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5

UPC-A、UPC-E、JAN13(EAN13)、JAN8(EAN8)、CODE39、CODABAR、ITF、CODE93、CODE128

QR code

QRCODE

Character Set

Common single-byte fonts：FONT 0 to FONT 8
TSS16、TST24、TSS24、K

12*24、9*17： number
24*24 ：Simplified Chinese、Korean、Traditional Chinese

Character enlargement/rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation printing

1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing

Paper type

Continuous, die-cut, fan-fold, black mark

Paper scroll core

25.4mm

Media width ( with liner)

25mm - 64mm

Paper Thickness

0.06mm - 0.254mm

Paper Roll Outer Diameter

90mm

Media Handling

tear-off

Paper Output Method

Top paper output

Printer Power Input

DC12V 2A

Power Adapter Output

/

Cash Drawer Output

5~40℃，20~90%non-condensing

Storage Environment

-25~55℃，20~93%non-condensing

Air Pressure

86~106kPa

Bare Weight (excluding paper roll)

750g

Packaging Weight (per unit)

1kg

External dimensions

180mm×130mm×125mm

Packaging dimensions

240mm×150mm×135mm

Outer box dimensions

635*260*455

Gross weight

13.04kg

Number of units per box

12

Print head (reliability)

30km

Printer certificate

CCC、SRRC、CE、FCC、ROHS

* The above parameters are subject to change without notice.
