Print method

Direct thermal

Resolution

203DPI

Print speed

2~8inch/s

Print width

80mm

Print head temperature detect

Thermal sensitive resistance

Print head position detect

Mircoswitch

Black mark position detect

Reflective sensors

Paper detect

Photoelectric sensor

Memory

DRAM:8M FLASH:8M

Interface

USB, USB+Bluetooth (optional)

Graphics

Monochrome PCX, BMP and other graphics files can be downloaded to FLASH/DRAM

1D Barcode

CODE128, EAN128, ITF, CODE39, CODE93, EAN13，EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR，POSTNET, UPC-A, UPC-A+2, UPC-A+5, UPC-E, UPC-E+2，UPC-E+5，CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14

2D Barcode

QRCODE

Character set

Common single-byte fonts: FONT 0 to FONT 8

Character enlargement / Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

Media type

Thermal roll paper, self-adhesive paper, etc.

Media thickness (with backing paper)

Max.0.254mm ((10mil).  Min.0.06mm (2.36mil)

Media width   (with backing paper)

Max.85mm (4.72"), Min,30mm (0.78")

Media roll core size

25.4mm~38mm (1"~1.5")

Media length

10-2286mm (0.39"~90")

Media diameter

160mm

Paper output method

Front paper output

Input

input: DC24V 2.5A

Working environment

5~40℃, 20~90%RH

Storage environment

-25~55℃, 20%~93%RH

Printer weight

0.83kg

Printer dimension

168×104×90mm

Packing dimension

240×150×137mm

Print head (reliability)

30km

Printer certificate

CE, FCC, CCC, RoHS, SRRC
