Print method

Direct thermal

Print command

Compatible with ESC/POS commands

Resolution

203DPI

Print width

72mm

Print head temperature detect

Thermal sensitive resistance

Print head position detect

Microswitch

Black mark detect

Reflective sensor

Paper detect

Transmissive sensor

Memory

FLASH:60K

Interface & Speed

Interface type

Default speed

Serial+USB/USB+Wi-Fi/USB+Bluetooth

160mm/s

Ethernet

200mm/s

Graphics

Support different density bitmap printing

Bar code

UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/ITF/CODABAR/CODE39/CODE93/CODE128/QRCODE

Character set

Standard GB18030 Simplified Chinese
ANK character: Font A: 12×24 dots, Font B: 9×17 dots
Simplified/Traditional Chinese: 24×24 dots

Character enlargement/rotation

1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing

Media type

Thermal roll paper

Media width

79.5士0.5mm

Media thickness

0.06-0.08mm

Media roll outer diameter

Max. 83mm

Media output method

Top paper output, partial-cut

Power supply

Input: DC24V 1.5A

Working environment

0~40℃, 30%~90% non-condensing

Storage environment

-20~55℃, 20%~93% non-condensing

Printer weight

0.95kg

Printer dimension

170mm×129mm×129mm

Packing dimension

260mm×230mm×210mm

Print head (reliability)

150km

Printer certificate

CCC, CE, FCC, RoHS

* The above parameters are subject to change without notice.
