Print method

Direct thermal

Print command

TSPL，ESC/POS

Resolution

203DPI

Print speed

60mm/s(max)

Print width

48mm

Print head temperature detect

Thermal sensitive resistance

Black mark detect

Thru Beam Sensors (right side)

Paper detect

Memory

SRAM:96K FLASH:8M

Interface

USB+Virtual Bluetooth

Graphics

Monochrome PCX, BMP and other image files can be downloaded to FLASH/DRAM

1D Barcode
2D Barcode

CODE128、EAN128、ITF、CODE39、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、QRCODE

Character set

Simplified Chinese: 24×24

Traditional Chinese: 24×24

Korean: 24×24

Character enlargement/rotation

1 ~10 times enlargement in portrait and landscape orientation

0°, 90°, 180°, 270°degree rotation

Media type

Continuous paper, gap paper, front black mark paper

Media width

40mm-58mm

Media roll outer diameter

50mm(max)

Media thickness

N/A

Media handling

Tear-off

Media output method

Top paper output

CPU

Cortex-A7(32bit) quad-core 1.1GHz

System memory

1GB RAM+ 8GB ROM

Operating system

Android 7.1.2

Expansion card

TF card (maximum 32GB)

Display

5.5 inch 720×1280 IPS LCD

Touch screen

Capacitive five-point touch screen

Wireless

IEEE 802.11b/g/n 2.4G

Network

2G/3G/4G full Netcom, B1/B3/B5/B8/B34/B38/B39/B40/B41

Speaker

1×1W

Bluetooth

BT4.1

SIM

Support 25mm×15mm standard card, single card

NFC

Support (optional)

Camera

8.0MP, AF

Scan head

Support (optional)

Interface

USB OTG+3.5mm earjack

Power adapter input

AC100-240V 50/60Hz 0.7A

Power adapter output

DC9V 2A

Built-in battery

3.7V/5000mAh

Charging time

<4.5 hours

Standby time (Wifi+Bluetooth)

7 days

Working environment

5~40℃, 20~90% non-condensing

Storage environment

-25~55℃, 20~93% non-condensing

Printer weight

560g

Printer dimension

218mm×90mm×75mm

Packing dimension

295mm×140mm×100mm

Print head (reliability)

50km

Printer certificate

CCC,SRRC,CTA

* The above parameters are subject to change without notice.
