Print method

 Direct thermal / Thermal transfer

Print command

TSPL

Resolution

300DPI

Print speed

2~4inch/s

Max. print width

108mm

Print head temperature detect

Thermal sensitive resistance

Print head position detect

Microswitch

Black mark detect

Reflective sensors (adjustable position)

Paper detect

Thru Beam Sensors (adjustable position)

Memory

DRAM:8M FLASH:4M

Interface

USB+Virtual Bluetooth

Graphics

Monochrome PCX, BMP and other image files can be downloaded to FLASH/DRAM

1D Barcode
2D Barcode

CODE128、EAN128、ITF、CODE39、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、POSTNET、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、CPOST、MSI、MSIC、PLESSEY、ITF14、EAN14、QRCODE

Character set

Common single-byte fonts: FONT 0 to FONT 8

Simplified Chinese: 24×24

Character enlargement/rotation

1 ~10 times enlargement in portrait and landscape orientation

0°, 90°, 180°, 270°degree rotation

Ribbon outer diameter

67mm (max)

Ribbon length

300m

Ribbon core size

25.4mm

Ribbon width

30mm-110mm

Ribbon rolling up method

Outward rolling

Media type

Continuous, die-cut, fan-fold, black mark

Media width

20mm-120mm

Media roll outer diameter

127mm(max)

Media thickness

0.06mm(2.36mil)-0.254mm(10mil)

Media roll core size

25.4mm(min）

Media handling

Cut off

Media output method

Front paper output

CPU

32-bit 4-core 1.1GHz

System memory

1GB RAM+ 8GB ROM

Operating system

Android 7.1.2

Expansion card

TF card (maximum 32GB)

Display

7 inch 720×1280 IPS LCD

Touch screen

Capacitive five-point touch screen

Wireless

IEEE 802.11b/g/n 2.4G

Network

2G/3G/4G full Netcom, B1/B3/B5/B8/B34/B38/B39/B40/B41

Speaker

1×1W

Bluetooth

BT4.1

SIM

Support 25mm×15mm standard card, single card

NFC

Support (optional)

Camera

8.0MP, AF

Scan head

Not support

Interface

USB OTG+Network port+4 X USB HOST

Power adapter input

AC100-240V 50/60Hz 2A

Power adapter output

DC24V 2.5A

Built-in battery

3.7V/1500mAh

Working environment

5~40℃, 20~90% non-condensing

Storage environment

-25~55℃, 20~93% non-condensing

Printer weight

3.6kg

Printer dimension

310mm×200mm×240mm

Packing dimension

418mm×263mm×283mm

Print head (reliability)

30km

Printer certificate

CCC,SRRC

* The above parameters are subject to change without notice.
