Print method

Direct Thermal

Print command

TSPL，CPCL，ESC/POS

Resolution

203DPI

Print speed

Receipt: 60mm/s(max)

Label: 60mm/s(max)

Print width

72mm

Print head temperature detect

Thermistor

Print head position detect

Micro Switch

Paper detect

Thru Beam Sensors, reflective Sensors

Sensor position

Keep Right

Memory

DRAM:8M FLASH:16M

Display

128×32 OLED

Interfaces

USB+Bluetooth

USB Port Spec.

Micro USB

Printing Width & Length

72mm×220mm

Graphics

Monochrome PCX, BMP and other image file printing

1D Barcode

CODE128, EAN128, ITF, CODE39, EAN13, EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR, UPC-A, UPC-A+2, UPC-A+5, UPC-E, UPC-E+2, UPC-E+5

2D Barcode

QRCODE

Character set

Simplified Chinese：16×16 20×20 24×24 32×32

Traditional Chinese：24×24

Korean：24×24

Character enlargement / Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

Media type

Continuous paper, label paper, Front black mark paper

Media width

25-80mm

Media diameter

50mm

Media output method

Top paper output

Power

Input：DC 5V 1A

Charging Time

Less than 4hrs

Battery Standby Time

N/A

Battery Working Time

N/A

Battery Capacity

7.4V/2200mAh

Working environment

5~40℃，20~90%RH

Storage environment

-25~55℃，20~93%RH

Pressure

86-106kPa

Printer weight (without battery)

308g

Printer weight (with battery)

417g

Printer Dimensions

130mm×112mm×65mm

Packing dimension

195mm×157mm×66mm

Print head (reliability)

30km

Printer certificate

CCC, SRRC, RoHS, UN38.3

* The above parameters are subject to change without notice.
