Print method

Direct Thermal

Print command

TSPL，CPCL，ESC/POS

Resolution

203DPI

Print speed

Receipt: 50mm/s(max)

Label: 40mm/s(max)

Print width

104mm

Print head temperature detect

Thermistor

Print head position detect

Micro Switch

Paper detect

Thru Beam Sensors, reflective Sensors

Sensor position

Keep Left

Memory

DRAM:8M FLASH:16M

Display

128×32 OLED

Interfaces

USB+bluetooth, USB+Bluetooth+Wi-Fi

USB Port Spec.

Type-C/Micro USB

Printing Width & Length

104mm×2286mm

Graphics

Monochrome PCX, BMP and other image file printing

1D Barcode

CODE128, EAN128, ITF, CODE39, EAN13, EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR, POSTNET, UPC-A, UPC-A+2, UPC-A+5, UPC-E, UPC-E+2, UPC-E+5, CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14

2D Barcode

QRCODE

Character set

Simplified Chinese：16×16 20×20 24×24 32×32

Traditional Chinese：24×24

Korean：24×24

Character enlargement / Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

Media type

Continuous paper, label paper, back black mark paper

Media width

25-112mm

Media diameter

50mm

Media output method

Top paper output

Power

Input：DC 5V 2A

Charging Time

Less than 4hrs

Battery Standby Time

N/A

Battery Working Time

N/A

Battery Capacity

7.4V/3000mAh

Working environment

5~40℃，20~90%RH

Storage environment

-25~55℃，20~93%RH

Pressure

86-106kPa

Printer weight (without battery)

440g

Printer weight (with battery)

542g

Printer Dimensions

127mm×147mm×64mm

Packing dimension

195mm×157mm×66mm

Print head (reliability)

30km

Printer certificate

CCC, SRRC, RoHS, UN38.3

* The above parameters are subject to change without notice.
