Print method

Direct Thermal

Print command

TSPL，CPCL，ESC/POS

Resolution

203DPI

Print speed

Receipt: 100mm/s(max)

Label: 60mm/s(max)

Print width

72mm

Print head temperature detect

Thermistor

Print head position detect

Micro Switch

Paper detect

Thru Beam Sensors, reflective Sensors

Sensor position

Keep Left

Memory

DRAM:8M FLASH:16M

Display

128×32 OLED

Interfaces

USB+Bluetooth

USB Port Spec.

Type-C

Printing Width & Length

72mm×2286mm

Graphics

Monochrome PCX, BMP and other image file printing

1D Barcode

CODE128, EAN128, ITF, CODE39, EAN13, EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR, POSTNET, UPC-A, UPC-A+2, UPC-A+5, UPC-E, UPC-E+2, UPC-E+5, CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14

2D Barcode

QRCODE, Datamatrix

Character set

Simplified Chinese：16×16 20×20 24×24 32×32

Traditional Chinese：24×24

Korean：24×24

Character enlargement / Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

Media type

Continuous paper, label paper, back black mark paper

Media width

20-80mm

Media diameter

51mm

Media output method

Top paper output

Power

Input：DC 5V 2A

Charging Time

Less than 2hrs

Battery Standby Time

100hrs

Battery Working Time

More than 300 meters (12.5% printing rate)

Battery Capacity

7.4V/2600mAh

Working environment

5~40℃，20~90%RH

Storage environment

-25~55℃，20~93%RH

Pressure

86~106kPa

Printer weight (without battery)

250g

Printer weight (with battery)

360g

Printer Dimensions

112mm×108mm×60mm

Packing dimension

195mm×157mm×66mm

Print head (reliability)

30km

Printer certificate

CCC, SRRC, RoHS, IP54, CE, FCC, UN38.3
