Printing method

Direct Thermal

Printing width

76mm or 64mm

Dot density

576 dot/line or 512 dot/line

Printing speed

250mm/s

Interfaces

USB+Serial+Parallel

Paper type

Paper Width：79.5 ±0.5mm，Paper OD：Φ80mm

Line spacing

3.75mm（Line spacing could be adjusted by commands）

Line spacing

Font A-42line or 48line/Font B-56line or 64line/Simplified/Traditional  Chinese-21line or 24line

Characters

Standard GB18030 Simplified Chinese

Fonts size

ANK fonts，Font A：1.5×3.0mm（12×24 dot）

Font B：1.1×2.1mm（9×17dot）

Simplified&Traditional  Chinese: 3.0×3.0mm(24×24dot)

Extended character table

PC437/Katakana/PC850/PC860/PC863/PC865/West Europe/

Greek/Hebrew/East Europe/Iran/WPC1252/PC866/PC852/

PC858/IranII/Latvian/Arabic/PT151,1251/PC737/WPC/

1257/Thai Vietnam/PC864/PC1001/(Latvian)/(PC1001)/

(PT151,1251)/(WPC1257)/(PC864)/(Vietnam)/(Thai)

Barcodes types

UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/

CODABAR/CODE93/CODE128

Input buffer

128K  bytes

NV Flash

256K bytes

Cash drawer output

DC 24V/1A

Power adaptor

DC 24V/2A

Power supply

Input：AC 110V/220V，50 ~ 60Hz　Output:DC 24/3A

Printer weight

1.70KG

Printer dimensions

154×192.5×136mm（W×L×H）

Working environment

Temperature:5~ 45℃， Humidity:10 ~ 80%

Storage environment

Temperature:-10 ~ 50℃ ，Humidity:10 ~ 90%（ RH）

Reliability

150KM

* The above parameters are subject to change without notice.
