• Printing Speed2~6inch/s
• 120mm Paper outlet design, wider label format is optional
• Single motor drives
• Transmissive sensor and reflective sensor, dual sensor design
• New three-interfaces mainboard design, in order to meet different interface requirements
• Added thermal transfer printing Method, more flexible in selecting consumables with longer storage time
• Integrated structure design, sturdy and durable, better consistency
• Brand-new transmission structure makes printing smoother
• Equipped cutter accessories, which is convenient for users to cut labels
Print method | Thermal Transfer/Direct Thermal |
Print speed | 2~6inch/s |
Interfaces | Serial + USB+Parallel |
Resolution | 203dots/inch(8dots/mm) |
Dot density | 0.125x0.125mm(1mm=8dots) |
Max. print width | 104mm or 108mm |
Max. print length | 2286mm(90°) |
Printer dimensions | 278x210x180(WxDxH) |
Printer weight | 2.09KG |
Working environment | 5~45℃(41~104℉),25~85% RH |
Storage environment | -10~50℃(-10~104℉),10~90% RH |
Pulse excitation | 1x108Pulses |
Print head (reliability) | 30KM |
Power | Input:AC 110V/240V. Output:DC24V/2.5V,60W |
Accessories | External media holder, auto-cutter are optional |
Ribbon diameter | Max. 67mm |
Ribbon length | 300m |
Ribbon core size | 1inch(2.54mm) |
Ribbon wdth | Max.110mm,Min.30mm |
Ribbon rolling up method | Printing side outward rolling |
Media diameter | 127mm(5′′)OD |
Media type | Continuous paper, gap paper, fan-fold paper, black mark paper |
Media rolling up method | Printing side outward rolling |
Media width | Max. 120mm(4.72′′)Min. 20mm(0.78′′) |
Media thickness (label + back paper) | Max. 0.254mm(10mil)Min. 0.06mm(2.36mil) |
Paper roll core size | 25.4mm~38mm(1′′~1.5′′) |
Gap paper spacing height | Min. 2mm(0.09′′) |
Label length | 10~2286mm(0.39′′~90′′)Note: if the label length is less than 25.4mm(1''), punched hole paper is suggested to be used |
