Print method

Direct Thermal

Print command

TSPL

Resolution

300DPI

Print speed

90mm/s

Print width

48mm

Print head temperature detect

Thermistor

Print head position detect

Micro Switch

Memory

DRAM:8M FLASH:4M

Interfaces

Serial + USB ports

Graphics

Monochrome PCX, BMP and other image file printing

1D Barcode
2D Barcode

UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/ITF/CODABAR/CODE39/CODE93/CODE128

Character set

GB18030 Simplified Chinese / 26 International Fonts

Character enlargement / Rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation

Media type

Continuous paper, label paper and more

Media width

60mm（±0.5mm）

Media diameter

65mm

Media output method

Top paper output

Power

Input：DC24V 2.5A

Working environment

5~45℃（41~113℉），25~85% RH

Storage environment

-10~50℃（14~122℉），10~90% RH

Printer weight

0.16kg

Printer dimensions

74mm×90mm×70mm

Packing dimension

294mm×213mm×181mm

Print head (reliability)

50km

* The above parameters are subject to change without notice.
