Print method

Direct thermal

Print command

ESC/POS

Resolution

203DPI

Print speed

180mm/s

Print width

72mm

Print head temperature detect

Thermal sensitive resistance

Print head position detect

Microswitch

Paper detect

Transmissive sensor

Memory

FLASH: 256K

Interface

Standard：USB+Ethernet

optional：

USB+Cash drawer

USB+Ethernet+Cash drawer

USB+Bluetooth+Cash drawer

USB+WiFi+Cash drawer

Graphics

Support different density bitmap printing

Barcode Type

UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/ITF/CODABAR/CODE39/CODE93/CODE128/QRCODE

Character set

Standard: GB18030 Simplified Chinese
Optional: GB18030, Traditional Chinese BIG5, Japanese font, Korean KSC5601(One or more Character set supported)

Character enlargement/rotation

1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing

Media type

Thermal roll paper (include environmental paper), Blackmark paper roll

Media width

79.5士0.5mm

Media roll outer diameter

Max. 82mm

Media thickness

0.06-0.08mm

Media handle

Partial-cut

Media output method

Top paper output

Sensor location

Middle

Wall mounting

Support

Power input

DC 24V 1.25A

Cash drawer output

DC 24V 0.5A

Working environment

00～45℃，20%～90% non-condensing

Storage Environment

-20~55℃，20%~93% non-condensing

Printer weight

0.57kg

Printer dimension

155mm×120mm×100mm

Packing dimension

225mm×150mm×120mm

Print head (reliability)

100km

Cutter (reliability)

1 million times

Printer certificate

CCC、RoHS
