Print method

Direct thermal

Print command

ESC/POS

Resolution

203DPI

Print speed

90mm/s(max)

Print width

48mm（max）

Print head temperature detect

Thermal sensitive resistance

Print head position detect

Microswitch

Paper detect

Photoelectric sensor

Memory

FLASH:60K

Interface

Standard：USB+Cash drawer

Optional：USB+Serial+Cash drawer

         USB+bluetooth+Cash drawer

Graphics

Support different density bitmap printing

Bar code

UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/ITF/CODABAR/CODE39/CODE93
/CODE128/QRCode

Character set

ANK character:
Font A: 12×24 dots
Font B: 9×17 dots
Simplified/Traditional Chinese: 24×24 dots

Character enlargement/rotation

Horizontal/vertical can be enlarged by 1-8 times, rotated and inverted printing

Media type

Thermal roll paper

Media width

57.5+0.5mm

Media thickness

0.06~0.08mm

Media diameter

60mm

Media output method

Top paper output

Power supply

DC12V 1A

Working environment

5~40℃，20~90%non-condensing

Storage Environment

-25~55℃，20~93%non-condensing

Printer weight

430g

Printer dimension

105mm×120mm×105mm

Packing dimension

180mm×150mm×125mm

Print head (reliability)

50km

Printer certificate

CCC、SRRC、CE、FCC、ROHS

* The above parameters are subject to change without notice.
