Print method

Direct thermal

Print method

receipt（ESC/POS）

label（TSPL）

Print resolution

203DPI

Print width

48mm（max）

Print speed

90mm/s(max)

Memory

FLASH:16MB

Print head temperature detect

Thermistor

Paper detect

photoelectric sensor

Printer Interfaces

USB+WiFi/USB+4G

Graphics

NVlogo

Monochrome PCX, BMP and other graphics files printing

Barcode

UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODE39/CODEBAR/ITF/CODE93/CODE128

CODE128/EAN128/ITF/CODE39/CODE93/EAN13/EAN13+2/EAN13+5/EAN8/EAN8+2/EAN8+5/CODEBAR/UPC-A/UPC-A+2/UPC-A+5/UPC-E/UPC-E+2/UPC-E+5

QR code

QRCODE

QRCODE

Character Set

ANK FontA:12*24 FontB:9*17

Simplified Chinese、Traditional Chinese、Korean:24*24

FONT0 to FONT8,

（1）Simplified Chinese：16x16、24x24（default）

（2）Simplified Chinese：24x24+trditional Chinese：24x24（optional）

（3）Simplified Chinese：24x24+Korean：24x24（optional）

Character enlargement/rotation

1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation printing

Media type

Thermal paper，die-cut、Continuous paper

Media width

57.5±0.5mm

25-58mm（with Liner）

Media diameter

59.5±0.5mm

Media thickness

0.06mm - 0.254mm

Media output method

Top paper output

Power input

DC12V ⎓ 1.5A

Working environment

5～45℃，20%～90%non-condensing

Storage environment

-25～55℃，20%～93%non-condensing

Printer weight

530g

Printer dimensions

120mmx105mmx105mm

Packing dimension

180mm×150mm×125mm

Print head (reliability)

50km

Printer certificate

CCC

* The above parameters are subject to change without notice.
