Print method

Direct thermal

Print Instructions

TSPL

ESC/POS

Resolution

203DPI

Print speed

90mm/s(max)

Print width

48mm(max)

Print head temperature detection

Thermistor

Print head position detection

Thermistor

Paper detection sensor

reflective sensor

Memory

FLASH:16MB

Button

Pause button, Feed button

Interface

USB

USB specifications

USB 2.0 Type-B

USB VID PID

 VID：0x0471 PID：0x0055

Max. printing specifications

58mm×120mm

\

Graphics

Monochrome PCX, BMP and other graphics files printing

NVlogo

Barcode

CODE128/EAN128/ITF/CODE39/CODE93/

EAN13/EAN13+2/EAN13+5/EAN8/EAN8+2/EAN8+5/

CODEBAR/UPC-A/UPC-A+2/UPC-A+5/UPC-E/UPC-E+2/UPC-E+5

UPCA/UPCE/JAN13(EAN13)/JAN8(EAN8)/

CODE39/ITF/CODABAR/CODE93/CODE128

QR code

QRCODE

QRCODE

Character Set

FONT0 to FONT8,
（1）Simplified Chinese：16x16、24x24（default）
（2）Simplified Chinese：24x24+trditional Chinese：24x24（optional）
（3）Simplified Chinese：24x24+Korean：24x24（optional）

Font A：12×24
Font B：9×17
simplified /traditional Chinese：24×24

Character enlargement/rotation

1 ~10 times enlargement in portrait and landscape orientation;  0°, 90°, 180°, 270°degree rotation printing

1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing

Paper type

Continuous,label paper

Continuous

Paper scroll core

12.7mm

\

Media width ( with liner)

57.5±0.5mm

25-58mm（with Liner）

Paper Thickness

0.06mm-0.254mm

Paper Roll Outer Diameter

59.5±0.5mm

Media Handling

Liner Removal

Paper Output Method

Top paper output

Printer Power Input

DC12V ⎓ 1.5A

Power Adapter Output

\

Cash Drawer Output

5～45℃，20%～90%non-condensing

Storage Environment

-25～55℃，20%～93%non-condensing

Air Pressure

86~106kPa

Bare Weight (excluding paper roll)

480g

Packaging Weight (per unit)

740g

External dimensions

120x105x105mm

Packaging dimensions

180mm×150mm×125mm

Outer box dimensions

569*322*406 MM,(L*W*H)

Gross weight

14.3kg

Number of units per box

18

Print head (reliability)

50KM

Printer certificate

CCC

* The above parameters are subject to change without notice.
