Print command

TSPL

Resolution

203DPI

Print speed

2~8inch/s（200mm/s）

Print width

104mm（max）

Overheat protection

Support

Media detection

Support

Black mark detection

Support

Cover open detection

Support

Media end detection

Support

Overheat protection

Thermistor

Head position detection

Microswitch

Media detection

reflective Sensors

Paper Detection

Thru Beam Sensors

Memory

FLASH:8MB

Interface

Standard: USB
Optional: USB + Bluetooth

Graphics

"Monochrome PCX, BMP and other image files
can be downloaded to FLASH/DRAM"

Barcode/QRcode

Barcodes: CODE128, EAN128, ITF, CODE39, EAN13, EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR, POSTNET, UPC-A, UPC-A+2, UPC-A+5, UPC-E, UPC-E+2, UPC-E+5, CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14
QR Code: QRCODE

Character set

Common single-byte fonts：FONT 0 to FONT 8

Character enlargement / Rotation

"""1 ~10 times enlargement in portrait and landscape orientation;
0°, 90°, 180°, 270°degree rotation printing"""

Media type

Continuous, die-cut, fan-fold, black mark

Media width(with liner)

25mm-118mm

Media core diameter

External Paper Roll

Media thickness

Max0.254mm，Min0.06mm

Media roll size

External Paper Roll

Paper output method

Front paper output

Media handling

Tear-off

Input

input：DC24V 2.5A

Operation environment

5~40℃，20%~90%non-condensing

Storage environment

-25~55℃，20%~93%non-condensing

Printer N.W

0.82kg

Printer dimension (D×W×H)

180mm×90mm×80mm

Packing dimension (D×W×H)

200mm×150mm×103mm

Box dimension

475mm×418mm×335mm

Packing G.W.(kg)

17.310kg

Quantity/box

12

Print head (reliability)

30km

Printer certificate

CCC、RoHS、SRRC

* The above parameters are subject to change without notice.
