Print command

TSPL

Resolution

203DPI

Print speed

2~8inch/s（200mm/s）

Print width

104mm（max）

Overheat protection

Support

Media detection

Support

Black mark detection

Support

Cover open detection

Support

Media end detection

Support

Overheat protection

Thermistor

Head position detection

Microswitch

Media detection

reflective Sensors

Paper Detection

Thru Beam Sensors

Memory

DRAM:8MB FLASH:4MB

Interface

Standard:USB

Optional:USB+Bluetooth、USB+WiFi

Graphics

"Monochrome PCX, BMP and other image files
can be downloaded to FLASH/DRAM"

Barcode/QRcode

CODE128、EAN128、ITF、CODE39、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、POSTNET、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、CPOST、MSI、MSIC、PLESSEY、ITF14、EAN14、QRCODE

Character set

Common single-byte fonts：FONT 0 to FONT 8

Character enlargement / Rotation

"""1 ~10 times enlargement in portrait and landscape orientation;
0°, 90°, 180°, 270°degree rotation printing"""

Media type

Continuous, die-cut, fan-fold, black mark

Media width(with liner)

25mm-118mm

Media core diameter

25.4mm~38mm

Media thickness

Max0.254mm，Min0.06mm

Media roll size

130mm(OD)

Paper output method

Front paper output

Media handling

Tear-off

Input

input：DC24V 2.5A

Operation environment

5~40℃，20%~90%non-condensing

Storage environment

-25~55℃，20%~93%non-condensing

Printer N.W

1.356 kg

Printer dimension (D×W×H)

219mm×178mm×159mm

Packing dimension (D×W×H)

312mm×230mm×225mm

Box dimension

715mm×475mm×332mm

Packing G.W.(kg)

13.856‬kg

Quantity/box

6

Cutter (reliability)

/

Print head (reliability)

30km

Printer certificate

CCC、RoHS、SRRC
