Print command

TSPL（Standard ），CPCL，ESC/POS

Resolution

203DPI

Print speed

100mm/s（Continuous）
70mm/s（label paper）

Print width

72mm

Overheat protection

Thermistor

Head position detection

Microswitch

Media detection

Thru Beam Sensor, reflective sensor

Sensor position

Left

Memory

RAM:4M   FLASH:16M

Display

128×64 OLED

Button

POWER/SAVE, FEED/SET, MENU

Interface

USB+Bluetooth

USB type

Type-C

USB VID PID

VID：0471 PID：0055

Max.printing specifications

72mm×300mm

Graphics

Monochrome PCX, BMP and other image file printing

Barcode

CODE128、EAN128、ITF、CODE39、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、POSTNET、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、CPOST、MSI、MSIC、PLESSEY、ITF14、EAN14

QR code

QRCODE、PDF417

Character set

Simplified Chinese（GB18030）：16*16、20*20、24*24
Traditional Chinese（BIG5）：24*24
Korean（KSC5601）：24*24

Character enlargement/rotation

1 ~10 times enlargement in portrait and landscape orientation;
0°, 90°, 180°, 270°degree rotation printing

Media type

Thermal paper, label paper, reverse black mark paper

Media width

25-80mm

Media thickness

0.06mm-0.17mm

Media roll outer diameter

51mm

Media output

Top paper output

Power supply

input：DC 5V 2A

Charging Time

≤3h

Battery Standby Time

≥96h

Battery print mileage

≥200m（12.5% printing rate）（25℃）

Battery cycle life

500times，≥80%

Battery capacity

7.4V/2600mAh

Working environment

5~40℃，20~90%non-condensing

Storage environment

-20~55℃，20~93%non-condensing

Pressure

86~106kPa

Printer N.W (without battery)

240g

Printer N.W (with battery)

346g

Printer G.W weight (with battery)

500g

Printer dimensions

114mm×105mm×60mm

Packing dimension

160mm×145mm×70mm

Box dimension

380mm×355mm×240mm

quantity/box（PSC）

18

Box Weight（KG）

9.75KG

Print head (reliability)

Receipt:  ≥150km (25% print density or less)/100 million pulses (25°C)
Label:  ≥50km (25% print density or less)/100 million pulses (25°C)

Printer certificate

CCC、SRRC、RoHS、CE、FCC、UN38.3、IP42

* The above parameters are subject to change without notice.
