Print command

Custom Command

Resolution

203DPI

Print speed

30-50mm/S Auto-Speed Adjustment

Print width

48mm

Overheat protection

Thermistor

Media detection

reflective sensor

Sensor position

Left

Memory

RAM:256k FLASH:1M

Button

FEED/POWER

Interface

USB+Bluetooth

USB type

Type-C

USB VID PID

VID：0471 PID：0055

Graphics

Monochrome PCX, BMP and other image file printing

Media type

Continuous、label paper

Media width

25-58mm

Media thickness

0.06mm-0.17mm

Media roll outer diameter

50mm

Media output

Top paper output

Power supply

input：DC 5V 1A

Charging Time

≤3h

Battery Standby Time

≥72h

Battery print mileage

≥200m（12.5% printing rate）（25℃）

Battery cycle life

500times，≥80%

Battery capacity

3.7V/1500mAh

Working environment

5~40℃，20~90%non-condensing

Storage environment

-20~55℃，20~93%non-condensing

Pressure

86~106kPa

Printer N.W (with battery)

240g

Printer G.W weight (with battery)

Subject to the actual packaging

Printer dimensions

88mm x 126mm x 63mm

Packing dimension

98mm×155mm×75mm

Box dimension

330mm×320mm×260mm

quantity/box（PSC）

18

Box Weight（KG）

6.6KG

Print head (reliability)

30km

Printer certificate

CCC、SRRC、UN38.3

* The above parameters are subject to change without notice.
