Print command

AUTO、TSPL、ESC/POS、CPCL

Resolution

203DPI

Print speed

Documents: 120mm/s (max)

Labels: 70mm/s (max)

Print width

72mm

Overheat protection

Thermistor

Head position detection

Microswitch

Media detection

Thru Beam Sensor, reflective sensor

Sensor position

Left

Memory

RAM:4M  FLASH:8M

Display

128×64 OLED

Button

POWER/SAVE, FEED/SET, MENU

Interface

USB+Bluetooth（1BLE+4SPP）

USB type

Type-C

USB VID PID

VID:0471 PID:0055

Max.printing specifications

72mm×300mm

Graphics

Monochrome PCX, BMP and other image file printing

Barcode

CODE128、EAN128、ITF、交叉25码、CODE39、CODE39C、CODE39S、CODE93、EAN13、EAN13+2、EAN13+5、EAN8、 EAN8+2、EAN8+5、CODABAR、POSTNET、UPC-A、UPCA+2、UPCA+5、UPC-E、UPCE+2、UPCE+5、MSI、MSIC、PLESSEY、ITF14、EAN14

QR Code

Character set

Common single-byte fonts：FONT 0 to FONT 8
Simplified Chinese（GB18030）：16*16、20*20
Traditional Chinese（BIG5）：24*24
Korean
Source Han Sans (Vector Font)

Character enlargement/rotation

TSPL:   2~30 times enlargement in portrait and landscape orientation;
CPCL:  as per the CPCL standard,  can be magnified  in portrait and landscape, 96*96 (MAX) ;
0°, 90°, 180°, 270°degree rotation printing

Media type

Thermal paper, label paper, front black mark paper

Media width

25-80mm

Media thickness

0.06mm-0.17mm

Media roll outer diameter

51mm

Media output

Top paper output

Power supply

input：DC 5V 1A

Charging Time

≤4h

Battery Standby Time

≥96h

Battery print mileage

≥200m（12.5% printing rate）（25℃）

Battery cycle life

500times，≥80%

Battery capacity

7.4V/2000mAh

Working environment

-10~50℃，20~90%non-condensing

Storage environment

-20~60℃，20~93%non-condensing

Pressure

86~106kPa

Printer N.W (without battery)

300g

Printer N.W (with battery)

400g

Printer G.W weight (with battery)

550g

Printer dimensions

88mm x 126mm x 63mm

Packing dimension

156mm×120mm×68mm

Box dimension

330mm×255mm×296mm

quantity/box（PSC）

16

Box Weight（KG）

  9.112KG

Print head (reliability)

Receipt:  ≥150km (25% print density or less)/100 million pulses (25°C)
Label:  ≥50km (25% print density or less)/100 million pulses (25°C)
Label:  ≥30km (60% print density or less)/100 million pulses (25°C)

Printer certificate

CCC、SRRC、CE、FCC、UN38.3、IP54

* The above parameters are subject to change without notice.
